Product Name: KMTA Series Precision Lock Nuts
Product Details
Drawing and Technical Data Sheet of KMTA series Precision Lock Nuts
| Precision Lock Nuts No. | G | Dm | D | B | m | n | M | N1 | N2 | P | Nm |
| mm | mm | mm | mm | mm | mm | mm | mm | mm | |||
| KMTA 5 | M 25x1.5 | 42 | 35 | 20 | 4.3 | 4 | M 6 | 8 | |||
| KMTA 6 | M 30x1.5 | 48 | 40 | 20 | 4.3 | 5 | M 6 | 8 | |||
| KMTA 7 | M 35x1.5 | 53 | 47 | 20 | 4.3 | 5 | M 6 | 8 | |||
| KMTA 8 | M 40x1.5 | 58 | 52 | 22 | 4.3 | 5 | M 6 | 8 | |||
| KMTA 9 | M 45x1.5 | 68 | 58 | 22 | 4.3 | 6 | M 6 | 8 | |||
| KMTA 10 | M 50x1.5 | 70 | 63 | 24 | 4.3 | 6 | M 6 | 8 | |||
| KMTA 11 | M 55x1.5 | 75 | 70 | 24 | 4.3 | 6 | M 6 | 8 | |||
| KMTA 12 | M 60x1.5 | 84 | 75 | 24 | 5.3 | 6 | M 6 | 8 | |||
| KMTA 13 | M 65x1.5 | 88 | 80 | 25 | 5.3 | 6 | M 6 | 8 | |||
| KMTA 14 | M 70x1.5 | 95 | 86 | 26 | 5.3 | 8 | M 8 | 18 | |||
| KMTA 15 | M 75x1.5 | 100 | 91 | 26 | 6.4 | 8 | M 8 | 18 | |||
| KMTA 16 | M 80x2 | 110 | 97 | 30 | 6.4 | 8 | M 8 | 18 | |||
| KMTA 17 | M 85x2 | 115 | 102 | 32 | 6.4 | 8 | M 10 | 35 | |||
| KMTA 18 | M 90x2 | 120 | 110 | 32 | 6.4 | 8 | M 10 | 35 | |||
| KMTA 19 | M 95x2 | 125 | 114 | 32 | 6.4 | 8 | M 10 | 35 | |||
| KMTA 20 | M 100x2 | 130 | 120 | 32 | 6.4 | 8 | M 10 | 35 | |||
| KMTA 22 | M 110x2 | 140 | 132 | 32 | 6.4 | 8 | M 10 | 35 | |||
| KMTA 24 | M 120x2 | 155 | 142 | 32 | 6.4 | 8 | M 10 | 35 | |||
| KMTA 26 | M 130x3 | 165 | 156 | 32 | 6.4 | 8 | M 10 | 35 | |||
| KMTA 28 | M 140x3 | 180 | 166 | 32 | 6.4 | 10 | M 10 | 35 | |||
| KMTA 30 | M 150x3 | 190 | 180 | 32 | 6.4 | 10 | M 10 | 35 | |||
| KMTA 32 | M 160x3 | 205 | 190 | 32 | 8.4 | 10 | M 10 | 35 | |||
| KMTA 34 | M 170x3 | 215 | 205 | 32 | 8.4 | 10 | M 10 | 35 | |||
| KMTA 36 | M 180x3 | 230 | 215 | 32 | 8.4 | 10 | M 10 | 35 | |||
| KMTA 38 | M 190x3 | 240 | 225 | 32 | 8.4 | 10 | M 10 | 35 | |||
| KMTA 40 | M 200x3 | 245 | 237 | 32 | 8.4 | 10 | M 10 | 35 |
